Serial to LoRa Gateway
GW-1104
Easy to install and set up.
Support either one Serial port (RS-232/RS-422/RS-485) to convert to LoRa.
Easy to install and set up.
Support either one Serial port (RS-232/RS-422/RS-485) to convert to LoRa.
Able to integrate with other devices with LoRa.
Support bidirectional transmission and communication.
Support wide input voltage range 12-24V
SPECIFICATION & I/O INTERFACE
| ZigBee frequency | 868 / 915MHz |
| Role | TX or RX |
| Memory | 512MB RAM |
| RS-232 | 1x DB-9 Male Connector |
| RS-422 | 1 x 2pins-phoenix terminal block For RS-422 only |
| RS-485 | 1 x 2pins-phoenix terminal block For RS-485 only |
Others
| Power Supply | 12-24V |
| Power Consumption | 3W |
| Operation Temp. | -20°C to 75°C (4°F to 167°F) |
| Storage Temp. | -40°C to 85°C (-40°F to 185°F) |
| Fixedness | Mounting ear with screws |
| Dimension | 100x 80x 30mm (3.9’’x 3.1’’x 1.2’’) |
